SUMMARY
Conversion Features |
---|
|
Specification Includes |
---|
|
Dimensions
mm | inches | |
---|---|---|
Entry Height | 1395 | 55 |
Max. Internal Headroom 1 | 1420 | 56 |
Lowered Floor Length | 1640 | 64.5 |
Lowered Floor Width at Entry | 760 | 30 |
Lowered Floor Width at Seats | 705 | 27.75 |
Max. Wheelchair Armrest Width 2 | 645 | 25.5 |
Access Ramp Length | 1130 | 44.5 |
Access Ramp Width | 730 | 28.75 |
Access Ramp Angle | 12.5º | |
Exterior Height | 1832 | 72 |
Exterior Length | 4500 | 177 |
Exterior Width (inc. Mirrors) | 2100 | 82.5 |
1 Internal headroom may vary depending on wheelchair travelling position.
2 In standard 2 rear seat configuration.
UK Type Approval No. g11*2018/858*00516
